Distinctions PTAC (DHP) - Cooling/Heat Pump/ Backup Electric Heat - 9,000-15,000 BTU/h

Distinctions
SKU:
DHP093A35AA
Availability:
0-8 Week Lead Time
(No reviews yet)
Current Stock:
$674.99
Adding to cart… The item has been added

Specifications & Details

Manufacturer Quick Description:



Sales, Support and Service You Can Trust



Five-Year Limited Warranty: Enjoy one of the most comprehensive warranties in the industry: First Year: parts & labor; Second through fifth years: parts & labor on certain sealed system components; second through fifth years: on certain functional parts only. For complete warranty details, visit www.distinctions-ptac.com.

Distinctions PTAC are stocked and sold from the same warehouse as the Amana® Brand PTAC products you have come to love over the years.





Features:

Dual Fan Motors: Allows precise independent fan speed operation while providing quiet operation.

LCDI Power Cord Included: No need to match power cord type to unit size.

3-Speed Fan: Provide precise comfort control to your guests.

Constant Fan: Take advantage of each unit’s dual options—select continuous fan operation or cycle the fan ON and OFF with the thermostat. Our 7-button design allows guests to select fan.

Wired Thermostat Compatible: Wire your PTAC with any standard thermostat for better temperature control



Advantages:

Energy Efficiencies: With EERs up to 13.1 and COPs up to 3.4, our unit’s high efficiencies may qualify you for many of the rebates offered by electrical power companies.

Automatic Emergency Heat: No more “my unit is not heating” complaints during the middle of the night. Heat pump units will automatically switch over to electric resistance heat if the heat pump compressor system fails or if the heating load is greater than the unit capacity.

Easy Pull-Out Filters: Our filters are washable and easy to maintain.

Condensate Dispersion System: Our condensate dispersion system removes condensate from indoor cooling operation by throwing water directly on to the outdoor coil for rapid evaporation and increased cooling efficiencies.





How to Identify PTAC Power Cord Configurations:

Power Cord to Electric Heater Size Conversion:

208/230 Volt (250V Power Cords)

15 Amp - 1.5 kW & 2.5 kW

20 Amp - 3.5 kW

30 Amp - 5.0 kW

265 Volt (277V Power Cords)

20 Amp - 1.5 kW & 2.5 kW & 3.5 kW

30 Amp - 5.0 kW



Unit Product Data:

R410A Model

    DHP093A25AA DHP093A35AA DHP093A50AA DHP123A25AA DHP123A35AA DHP123A50AA DHP153A35AA DHP153A50AA DHP094A35AA DHP124A35AA
COOLING
Voltage V 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 265 265
Capacity Btu/h 9000/8800 9000/8800 9000/8800 12000/11800 12000/11800 12000/11800 14700/14500 14700/14500 9000 12000
Amps A 3.46/3.75 3.46/3.75 3.46/3.75 5.0/5.4 5.0/5.4 5.0/5.4 6.03/6.58 6.03/6.58 3.01 4.31
Watts W 796/778 796/778 796/778 1142/1124 1142/1124 1142/1124 1390/1370 1390/1370 796 1142
EER Btu/h/W 11.4 11.4 11.4 10.5 10.5 10.5 10.6 10.6 11.3 10.5
CFM (Cool/Wet Coil) High Speed   431 431 431 387 387 387 374 374 388 379
CFM (Cool/Wet Coil) Low Speed   333 333 333 309 309 309 312 312 321 313
CFM (DRY) High Speed   431 431 431 387 387 387 374 374 388 380
CFM (DRY) Low Speed   333 333 333 309 309 309 312 312 322 314

UNIVERSAL
Vent Door CFM   61.1/57.6/50.6 61.1/57.6/50.6 61.1/57.6/50.6 62/60/56 62/60/56 62/60/56 62/60/56 62/60/56 61.1/57.6/50.6 62/60/56
Dehumidification (Pints/Hr)   1.06 1.06 1.06 2.81 2.81 2.81 4.29 4.29 1.06 2.81
Net Weight lbs 102.51 102.51 102.51 115.96 115.96 115.96 116.84 116.84 101.19 113.1
Ship Weight lbs 112.88 112.88 112.88 125.44 125.44 125.44 126.54 126.54 111.99 126.76

ELECTRIC HEAT
Voltage V 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 265 265
Heater Size (kW)   2.5 3.5 5 2.5 3.5 5 3.5 5 3.5 3.5
Heating Capacity Btu/h 7800/6300 10900/8900 15000/12200 7800/6300 10900/8900 15000/12200 10900/8900 15000/12200 10900 10900
Watts W 2,535/2,080 3535.5/2897 4769/3953 2,535/2,080 3535/2900 4769/3953 3535/2900 4769/3953 3500 3500
Amps A 10.8/9.8 15.3/13.7 22/19.7 10.8/9.8 15.3/13.7 22/19.7 15.3/13.7 22/19.7 13.46 13.46

REVERSE CYCLE
Voltage V 208/230 208/230 208/230 208/230 208/230 208/230 208/230 208/230 265 265
Capacity Btu/h 8100/7900 8100/7900 8100/7900 10800/10500 10800/10500 10800/10500 13500/13200 13500/13200 8100 10800
Amps A 3.04/3.28 3.04/3.28 3.04/3.28 4.3/4.6 4.3/4.6 4.3/4.6 5.38/5.82 5.38/5.82 3.1 4.3
Watts W 700/680 700/680 700/680 990/963 990/963 990/963 1237/1209 1237/1209 719 989
COP W/W 3.40 3.40 3.40 3.2 3.2 3.2 3.20 3.20 3.3 3.2
CFM (DRY)   431 431 431 387 387 387 374 374 388 380

1. All 265-volt models must use an Amana brand sub-base (PTSB4**E) or an Amana brand hard-wire kit PTPWHWK4 and disconnect switch PSHW04A.

2. Minimum Circuit Ampacity (MCA) ratings conform to the National Electric Code; however, local codes should apply.

3. Minimum voltage on 230/208-volt models is 197 volts; maximum is 253 volts. Minimum voltage on 265-volt models is 239 volts; maximum is 292 volts.

4.Overcurrent protection for all units without electric heaters is 15 amps. Overcurrent protection on 265-volt models must be cartridge-style time-delay fuses (included and factory-installed on all Amana brand 265-volt chassis). See heater performance.

5.Heating capacity and efficiency based on unit operation without condensate pump.



6. Specify two-digit heater kW size to complete model number.

7. R-410A or R-32 refrigerant used in all systems.

8. All units meet or exceed ASHRAE 90.1 standards.

9. All units less than 250 volts have a Leak Current Detector Interrupter (LCDI) power cord and meet UL 484 standards.

10. Refer to electric heat performance data for total MCA and recommended overcurrent protection. Amps and watts notation refers to compressor only.

11. All models, specification, decriptions, and data are not verified and subject to change. Verify information with manufacturer prior to purchase.



Manufacturers Standard Warranty: 1 Year Parts and Labor Full Unit 2-5 Years Parts 2-5 Years Part and Labor Sealed System * Confirm full warranty with manufacturer.
